HAYWARD TC20150ST TC Series True Union Ball Check Valve, 1-1/2 in Nominal, Socket/Threaded End Style, CPVC Body, FKM Softgoods
HAYWARD TC20150ST 1-1/2" CPVC TRUE UNION BALL CHECK VALVE, VITON SEAT
Ball Check Valves
}
HAYWARD TC20150ST TC Series True Union Ball Check Valve, 1-1/2 in Nominal, Socket/Threaded End Style, CPVC Body, FKM Softgoods
174614
MFG #: TC20150ST
Product ID:174614
Famous Supply
- Dimensions: 4 in H
- Inlet to Outlet Length: 6-3/4 in
- Port Type: Full
- Pressure Rating: 235 psi
- Series: TC Series
- Temperature Rating: 70 deg f
- Type: True Union
- Nominal Size: 1-1/2 in
- End Style: Socket/Threaded
- Body Material: CPVC
- Softgoods Material: FKM
TC Series true union ball check valves are offered in PVC, CPVC, and PP. O-rings and seats are FPM or EPDM. 1/4 in. and 3/8 in. sizes are PVC only and are trim check design. They have socket or threaded end connections. Others up to 2 in. sizes have socket and threaded end connections. All valves are assembled with silicone free lubricant.
- Features
- Warranty
- Standards & Approvals
- Application
| For horizontal or vertical installation |
| Square cut seat for positive sealing |
| Seats with minimum back pressure |
| Sure block design |
| FPM O-ring |
| 2 Years |
| Class 23447 per ASTM D1784 |
| NSF/ANSI 61 |
| Water and Wastewater Treatment, Chemical Processing, Food and Beverage, Swimming Pools and Water Parks, Aquaculture, Aquarium and Zoo Service, Pharmaceutical, Pulp and Paper, Landfill Service, Marine and Corrosive Environments, Metal Finishing and Plating |
